    Unless specified otherwise, all of the below tinting applies to both Lollipop and pre-Lollipop using AppCompat v21. To use the support version of these attributes, remove the android namespace. For instance, "android:colorControlNormal" becomes "colorControlNormal". These attributes will be propagated to their corresponding attributes within the android namespace for devices running Lollipop. Any exceptions to this will be noted by including the "android:" prefix.

    All Clickable Views:
    -----------
    * ripple effect (Lollipop only) -- "colorControlHighlight"

    Status Bar:
    ------------
    * background (Lollipop only) - "colorPrimaryDark"

    Navigation Bar:
    ----------------
    * background (Lollipop only) - "android:navigationBarColor"

    EditText:
    ----------
    * underline (unfocused) -- "colorControlNormal"
    * underline overlay (focus) -- "colorAccent"
    * cursor -- "colorAccent"
    * text color -- "android:textColorPrimary"

    CheckBox:
    ----------
    * box unchecked -- "colorControlNormal"
    * box checked -- "colorAccent"

    RadioButton:
    -------------
    * unselected -- "colorControlNormal"
    * selected -- "colorAccent"
    * ripple effect (Lollipop only) -- "colorControlHighlight"

    Spinner:
    ---------
    * indicator (not pressed) -- "colorControlNormal"
    * indicator (pressed) -- "colorAccent"
    * selected entry text color (Lollipop only) -- "android:textColorPrimary"

    ActionBar:
    -----------
    * background -- "colorPrimary"
    * title color -- "android:textColorPrimary"
    * overflow icon -- "android:textColorPrimary"
    * up button -- "android:textColorPrimary"
    * action icons -- "android:textColorPrimary" †
    * overflow menu background -- "android:colorBackground"
    * overflow text color -- "android:textColorPrimary"

    Toolbar (Theme Overlay should be used):
    ----------------------------------------
    * background -- must be set manually in XML. Can do (android:background="?attr/colorPrimary")
    * overflow icon -- "android:textColorPrimary"
    * navigation icon -- "android:textColorPrimary" †
    * action icons -- "android:textColorPrimary" †
    * overflow menu background -- "android:colorBackground"
    * overflow text color -- "android:textColorPrimary"


    † tinting by default only works with whitelisted stock action icons (see TintManager source code). For instance, the back arrow icon "abc_ic_ab_back_mtrl_am_alpha" is tinted, but copying that exact file and renaming it will result in the icon not being tinted while taking a random image and renaming it to "abc_ic_ab_back_mtrl_am_alpha" will result in it being tinted. Tinting can be done in XML in Lollipop by creating a <bitmap> xml file in drawable and applying the "android:tint" attribute. This icon can be used in both Lollipop and pre-Lollipop, but it will only be tinted in Lollipop. Tinting of action icons can also be done programmatically using a ColorFilter.
