Content Management: Restaurant Directory

What is Content Management?

Wikipedian answer: "A content management system (CMS) is a computer application that allows publishing, editing and modifying content, organizing, deleting as well as maintenance from a central interface. Such systems of content management provide procedures to manage workflow in a collaborative environment."

More simply put: Content management is the administration of digital content throughout its lifecycle. The content involved may be any combination of images, video, audio, multimedia, or text. This includes the creation, editing, publishing, overseeing, as well as the eventual removal / storage of that content.

In a graph you can map out these assets in a 1:1 ratio as documents or in as granular manner as your use-case demands. It really comes down to how *YOU want* to model your information.

Data Model

Here is the data model I have chosen for my Yelp / Restaurant directory. I’ve chosen to isolate the frequently updated assets that would be likely be reused across many different webpages. I’ve also added "active" property on the relationships between a given restaurant and its associated assets and a timestamp() on the deactivated pieces of content. We’ll see later on in this Gist how this property allows us to easily update, keep track of, publish the correct information as well delete pieces of content.

Building our database

Create some constrains. For example, The Taco Bells are rampant. Rather than have many different "Taco Bell” duplicates, we will have one restaurant node, with several (or many) location nodes both active and inactive branching off.

Also, note that you can’t run several constraints all in one statement in browser (in gist). If you would like to do them all at once, you’re better off using the Neo4j shell. Here, we’re protecting ourselves creating duplicates of content inside of our directory. If duplication is a major issue for your team, check out this Gist on merging nodes.

CREATE CONSTRAINT ON (a:City) ASSERT a.name IS UNIQUE;
CREATE CONSTRAINT ON (a:ZipCode) ASSERT a.zip IS UNIQUE;
CREATE CONSTRAINT ON (a:State) ASSERT a.name IS UNIQUE;
CREATE CONSTRAINT ON (a:Location) ASSERT a.address IS UNIQUE;
CREATE CONSTRAINT ON (a:Account) ASSERT a.name IS UNIQUE;
CREATE CONSTRAINT ON (a:Email) ASSERT a.email IS UNIQUE;
CREATE CONSTRAINT ON (a:Category) ASSERT a.name IS UNIQUE;
CREATE CONSTRAINT ON (a:URL) ASSERT a.url IS UNIQUE;
CREATE CONSTRAINT ON (a:Restaurant) ASSERT a.name IS UNIQUE;
CREATE CONSTRAINT ON (a:Phone) ASSERT a.number IS UNIQUE;

Importing Data (Load CSV)

I’ve hosted my data at the URL: https://dl.dropboxusercontent.com/u/313565755/California_Rest.csv in an effort to illustrate in some small fashion how to import a CSV into Neo4j and how to manipulate that data to create nodes, relationships, and properties. For a more in depth read on how to import data using LOAD CSV, read the legendary Michael Hunger’s blog posts Part I, Part II.

There are a few things I’d like to point out:

First, use a periodic commit. While for this very small dataset it isn’t necessary, we recommend it in nearly all cases when running a LOAD CSV. This prevents large transactions from overflowing your available database memory (JVM Heap).

I’d also like to point out how to separate out multiple pieces of information contained under the same header. In this CSV, we have many restaurants that are classified with multiple categories, e.g., "Fast Food, Mexican, Big Portions." If left unmodified, Neo4j would import that list as a single string. We can use SPLIT() to tell Neo4j to split that string into an array. We then use UNWIND to transform this collection into individual rows. (Split Documentation, Unwind Documentation)

Lastly, we should note that Neo4j’s LOAD CSV pulls everything in as a string unless instructed otherwise. We can use toINT or toFLOAT to have Neo parse the string as if it was an floating point number or an integer (Scalar Function Documentation)

USING PERIODIC COMMIT 1000
LOAD CSV WITH HEADERS from "https://dl.dropboxusercontent.com/u/313565755/California_Rest.csv" AS line
WITH line, SPLIT(line.Categories, ",") AS cats, toFloat(line.Latitude) AS lats, toFloat(line.Longitude) AS longs
UNWIND cats AS cat
MERGE (a:Account {name:line.Account})
MERGE (c:Contact {name:line.Restaurant_Name+" "+"Contact Info"})
MERGE (p:Phone {number:line.Phone_Number, created:timestamp()})
MERGE (r:Restaurant {name:line.Restaurant_Name})
MERGE (e:Email {email:line.Email, created:timestamp()})
MERGE (l:Location {address:line.Street_Address, lat:lats, long:longs})
MERGE(s:State {name:line.State})
MERGE (z:ZipCode {zip:line.Zip_Code})
MERGE (t:City {name:line.City})
MERGE (y:Category {name:cat})
MERGE (b:URL {url:line.Website})
WITH a,c,r,l,p,e,s,z,t,y,b
MERGE (a)-[:HAS_RESTAURANT {active:true}]->(r)
MERGE (r)-[:HAS_CONTACT {active:true}]->(c)
MERGE (l)-[:HAS_PHONE {active:true}]->(p)
MERGE (c)-[:HAS_EMAIL {active:true}]->(e)
MERGE (c)-[:HAS_WEBSITE {active:true}]->(b)
MERGE (r)-[:HAS_LOCATION {active:true}]->(l)
MERGE (l)<-[:HAS_ADDRESS]-(z)<-[:HAS_ZIPCODE]-(t)<-[:HAS_CITY]-(s)
MERGE (r)-[:IN_CATEGORY]->(y);

Let’s inspect our data!

What is Related and How?

This is a query I use all the time, it helps me remember how my data is tied together. This will return the node types and the relationships between given node types. You’ll notice that this query ships with Neo4j under starred queries in the sidebar.

MATCH (a)-[r]->(b)
RETURN DISTINCT head(labels(a)) as THIS, type(r) as TO, head(labels(b)) as THAT
limit 15

Let’s start with an :Account node…​.

MATCH (a:Account)
RETURN a
limit 1

double click

MATCH (a:Account {name:'Yum Foods'})-[:HAS_RESTAURANT]-(b)
RETURN a,b

double click, double double click

MATCH (a:Account {name:'Yum Foods'})-[:HAS_RESTAURANT]-(b:Restaurant)-[:HAS_LOCATION]-(c)
RETURN a,b,c

click, click, clicky, click

MATCH (a:Account {name:'Yum Foods'})-[:HAS_RESTAURANT]-(b:Restaurant)-[:HAS_CONTACT]-(c)-[]-()
RETURN a,b,c

"Publishing" our Content

If we were Yelp, or some similar directory service when a user loads a page-- we need to make sure that we’re service them the correct content and information. Check out Structr, it’s a natural extension of this content management example. It’s a CMS that uses Neo4j to help users build web applications.

This is where our r.active property comes into play. When we make requests, we’ll ask for only pieces of content whose adjoining relationships are r.active = true.

MATCH (a:Restaurant {name:'Taco Bell'})-[:HAS_LOCATION {active:true}]->(loc:Location)-[rr:HAS_PHONE {active:true}]->(fone:Phone)
RETURN a.name as Restaurant, loc.address as Location, fone.number as PhoneNumber

What does this look like visually?

MATCH x=(a:Restaurant {name:'Taco Bell'})-[:HAS_LOCATION {active:true}]->(l:Location)-[:HAS_PHONE {active:true}]->(p:Phone)
RETURN x

Graph Search

"Find me a restaurant that serves fast food located in my zip code"

match search = (:ZipCode {zip:'95630'})-[:HAS_ADDRESS]->(:Location)<-[:HAS_LOCATION]-(rest:Restaurant)-[:IN_CATEGORY]-(:Category {name:'Fast Food'})
return search

"Understanding" our Content

As an enterprise you’re going to want to quantitatively identify your key accounts. In this model, we’ll decide on key accounts based on number of restaurant locations associated with a given account. If we so chose, we could also add cost / revenue values to the relationships and then perform an aggregation on them.

MATCH (a:Account)-[:HAS_RESTAURANT {active:true}]->(r:Restaurant)-[:HAS_LOCATION {active:true}]->(l:Location)
RETURN a.name as Account, count(*) as Number_Of_Locations
ORDER BY count(*) DESC
LIMIT 3

"Updating" our Content

Updating a lot of Information inside our CMS…​

USING PERIODIC COMMIT 1000
LOAD CSV WITH HEADERS from "https://dl.dropboxusercontent.com/u/313565755/newphones.csv" AS line
WITH line
MATCH (rest:Restaurant {name:line.Restaurant_Name})-[:HAS_LOCATION]->(loc:Location)-[rel:HAS_PHONE]-(fone:Phone)
WITH rest,loc,rel,fone,line
MERGE(p:Phone {number:line.newphone})
MERGE(loc)-[rel2:HAS_PHONE]->(fone)
ON CREATE SET rel2.active=true, rel2.created=timestamp(),rel.active=false,rel.deactivated=timestamp()
RETURN rest.name AS RESTAURANT,rel2.active AS ACTIVE, fone.number AS PHONE_NUMBER

Updating a little bit of information inside our CMS.

Let’s pretend that Yum Foods has decided to merge all of its phone lines into a single customer service hotline

MATCH (:Account {name:'Yum Foods'})-[:HAS_RESTAURANT]-(:Restaurant)-[:HAS_LOCATION]-(loc:Location)-[r:HAS_PHONE]-(oldfone:Phone)
SET r.active = 'false', r.deactivated=timestamp()
MERGE (newfone:Phone {number:'1-800-YUM-FOOD'})
CREATE (loc)-[:HAS_PHONE {active:'true', created:timestamp()}]->(newfone)
RETURN loc, r, newfone

Let’s now take a look at some of our inactive phone numbers…​

MATCH (a:Account {name:'Yum Foods'})-[:HAS_RESTAURANT]->(rest:Restaurant)-[:HAS_LOCATION]-(l:Location)-[rel:HAS_PHONE]-(fone)
RETURN rest.name as WHERE, rel.active as ACTIVE_STATUS, fone.number as PHONE_NUMBER

The End
