Mix.install([
{:kino, "~> 0.15.3"},
{:runic, github: "zblanco/runic", branch: "zw/map"},
{:req, "~> 0.5.10"},
{:server_sent_events, "~> 0.2.1"},
{:ecto, "~> 3.12"}
])llm_api_url_input = Kino.Input.text("LLM API URL", default: "https://api.groq.com/openai/v1/chat/completions")model_input = Kino.Input.text("Model", default: "llama-3.1-8b-instant")max_tokens_input = Kino.Input.text("Max Tokens", default: 512)llm_api_key_input = Kino.Input.password("LLM API Key", default: System.get_env("GROQ_API_KEY"))llm_api_url = Kino.Input.read(llm_api_url_input)
model = Kino.Input.read(model_input)
max_tokens = Kino.Input.read(max_tokens_input)
llm_api_key = Kino.Input.read(llm_api_key_input)
:ok defmodule LLMTools do
@chat_completion_opts ~w(
model
messages
frequency_penalty
max_completion_tokens
n
parallel_tool_calls
presence_penalty
reasoning_format
response_format
seed
service_tier
stop
stream
temperature
tool_choice
tools
top_logprobs
top_p
user
)a
# @default_system_prompt """
# You are a fiercely intelligent assistant and friend of the user.
# Your purpose and drive is to assist the user with any request they have.
# You provide helpful measured responses that take the user seriously.
# You provide precise and clear descriptions using helpful analogies
# and other communication techniques to convey the core models of a subject.
# """
def prompt_chat_completion(message, opts \\ [])
def prompt_chat_completion(message, opts) when is_binary(message) do
prompt_chat_completion([%{role: :user, content: message}], opts)
end
def prompt_chat_completion([%{role: _, content: _} | _] = messages, opts) do
opts
|> Keyword.put(:messages, messages)
|> generate_response()
|> extract_llm_response()
end
def generate_response!(opts \\ []) do
api_key = opts[:api_key] || raise(ArgumentError, "`api_key` is required")
url = opts[:url] || raise(ArgumentError, "`url` is required")
opts[:messages] || raise(ArgumentError, "`messages` is required")
opts[:model] || raise(ArgumentError, "`model` is required")
opts = Keyword.take(opts, @chat_completion_opts)
Req.post!(url,
json: Map.new(opts),
auth: {:bearer, api_key}
)
end
def generate_response(opts \\ []) do
api_key = opts[:api_key] || raise(ArgumentError, "`api_key` is required")
url = opts[:url] || raise(ArgumentError, "`url` is required")
opts[:messages] || raise(ArgumentError, "`messages` is required")
opts[:model] || raise(ArgumentError, "`model` is required")
opts = Keyword.take(opts, @chat_completion_opts)
Req.post(url,
json: Map.new(opts),
auth: {:bearer, api_key},
receive_timeout: 60_000,
pool_timeout: 30_000
)
end
def extract_llm_response({:ok, response}) do
extract_llm_response(response)
end
def extract_llm_response(%Req.Response{status: 200, body: body}) do
body
|> Map.get("choices")
|> hd()
|> Map.get("message")
|> Map.get("content")
end
def stream_response!(opts \\ []) do
timeout = opts[:timeout] || 60_000
api_key = opts[:api_key] || raise(ArgumentError, "`api_key` is required")
url = opts[:url] || raise(ArgumentError, "`url` is required")
opts[:messages] || raise(ArgumentError, "`messages` is required")
opts[:model] || raise(ArgumentError, "`model` is required")
opts = Keyword.take(opts, @chat_completion_opts)
pid = self()
Stream.resource(
fn ->
Task.async(fn ->
options =
[
json: Map.merge(%{stream: true}, Map.new(opts)),
receive_timeout: timeout,
auth: {:bearer, api_key},
into: fn {:data, data}, {req, resp} ->
buffer = Req.Request.get_private(req, :sse_buffer, "")
{events, buffer} = ServerSentEvents.parse(buffer <> data)
Req.Request.put_private(req, :sse_buffer, buffer)
if events != [] do
send(pid, events)
end
{:cont, {req, resp}}
end
]
Req.post(url, options)
send(pid, :done)
end)
end,
fn task ->
receive do
:done ->
{:halt, task}
data ->
{[data], task}
after
15_000 ->
{:halt, task}
end
end,
fn task -> Task.await(task, 15_000) end
)
end
enddefmodule Kino.Cytoscape do
use Kino.JS
def new(g, options \\ [])
def new(%Graph{} = graph, options) do
graph
|> to_edgelist_json()
|> new(options(options))
end
def new(edge_list, options) when is_list(options) do
nodes =
edge_list
|> Enum.flat_map(fn %{data: edge} ->
[
%{data: %{id: "#{edge.source}", name: "#{edge.source}"}},
%{data: %{id: "#{edge.target}", name: "#{edge.target}"}}
]
end)
|> Enum.uniq_by(& &1.data.id)
new(nodes ++ edge_list, options(options))
end
def new(graph, options) do
Kino.JS.new(__MODULE__, Map.put(options, :elements, graph))
end
defp options(:dag) do
options = options([])
dag_layout = %{
name: "breadthfirst",
fit: true,
directed: true,
avoidOverlap: true,
spacingFactor: 1.0,
grid: false,
padding: 0,
anime: true,
circle: false,
userZoomingEnabled: true
}
Map.put(options, :layout_options, dag_layout)
end
defp options(options) do
cytoscape =
options[:cytoscape] ||
%{
"zoomingEnabled" => true,
"userZoomingEnabled" => true,
"panningEnabled" => true,
"userPanningEnabled" => true,
"boxSelectionEnabled" => false
}
node_style =
options[:node_style] ||
%{
"background-color" => "#ffffff",
"font-size" => 14,
"width" => 120,
"shape" => "ellipse",
"height" => 80,
"text-wrap" => "wrap",
"text-max-width" => 56,
"color" => "#475569",
"label" => "data(name)",
"text-halign" => "center",
"text-valign" => "center",
"border-width" => 2,
"border-color" => "#94a3b8",
"border-opacity" => 0.5
}
edge_style =
options[:edge_style] ||
%{
"width" => 2,
"font-size" => 12,
"label" => "data(label)",
"line-color" => "#94a3b8",
"target-arrow-color" => "#94a3b8",
"target-arrow-shape" => "triangle",
"curve-style" => "bezier"
}
layout_options =
options[:layout_options] ||
%{
name: "cose",
fit: true,
directed: true,
avoidOverlap: true,
spacingFactor: 1.0,
grid: false,
padding: 0,
anime: true,
circle: false,
userZoomingEnabled: true
}
%{
cytoscape: cytoscape,
node_style: node_style,
edge_style: edge_style,
layout_options: layout_options
}
end
defp to_edgelist_json(graph) do
vertices =
graph
|> Graph.vertices()
|> Enum.map(fn v ->
vertex_label = vertex_label(v)
%{data: %{id: "#{vertex_label}", name: "#{vertex_label}"}}
end)
edges =
graph
|> Graph.edges()
|> Enum.map(fn edge ->
edge_label = edge_label(edge.label)
v1 = vertex_label(edge.v1)
v2 = vertex_label(edge.v2)
%{
data: %{
id: "#{edge_label}-#{v1}#{v2}" |> :erlang.phash2(),
label: "#{edge_label}",
source: v1,
target: v2
}
}
end)
vertices ++ edges
end
defp edge_label(label), do: label
defp vertex_label({_, _, _} = ast), do: Macro.to_string(ast)
defp vertex_label(%Runic.Workflow.Root{}), do: :root
defp vertex_label(%{name: name}) when not is_nil(name), do: name
defp vertex_label(%{__struct__: struct} = vertex),
do: "#{to_string(struct)}#{:erlang.phash2(vertex)}"
defp vertex_label(otherwise), do: otherwise
asset "main.js" do
"""
import "https://cdn.jsdelivr.net/npm/[email protected]/dist/cytoscape.min.js";
export function init(ctx, cyto_data) {
ctx.root.innerHTML = `<div id='cyto' style='width: 896px; height: 400px;'></div>`;
var cy = cytoscape({
...cyto_data.cytoscape,
...{
container: document.getElementById('cyto'),
elements: cyto_data.elements,
style: [
{
selector: 'node',
style: cyto_data.node_style
},
{
selector: 'edge',
style: cyto_data.edge_style
}
]
}
});
cy.layout(cyto_data.layout_options).run();
}
"""
end
endrequire Runic
import Runic
require Logger
alias Runic.Workflowfrench_translator =
step(
fn input ->
LLMTools.generate_response!(
model: model,
api_key: llm_api_key,
max_tokens: 512,
url: llm_api_url,
messages: [
%{role: "user", content: "Translate the following text to French: #{input}"}
]
)
end,
name: :french_translator
)
spanish_translator =
step(
fn input ->
LLMTools.generate_response!(
model: model,
api_key: llm_api_key,
max_tokens: 512,
url: llm_api_url,
messages: [
%{role: "user", content: "Translate the following text to Spanish: #{input}"}
]
)
end,
name: :spanish_translator
)
extract_translation =
step(&LLMTools.extract_llm_response/1, name: :extract)wrk =
workflow(
name: "language translator",
steps: [
french_translator,
spanish_translator
]
)
|> Workflow.add(extract_translation, to: :spanish_translator)
|> Workflow.add(extract_translation, to: :french_translator)
# attach hooks for debugging intermediate results
|> Workflow.attach_after_hook(:spanish_translator, fn _step, wrk, fact ->
IO.inspect("## Component: spanish_translator has produced output: #{inspect(fact.value)}")
wrk
end)
|> Workflow.attach_after_hook(:french_translator, fn _step, wrk, fact ->
IO.inspect("## Component: french_translator has produced output: #{inspect(fact.value)}")
wrk
end)wrk.graph
|> Kino.Cytoscape.new(
layout_options: %{
name: "breadthfirst",
fit: true,
directed: true,
avoidOverlap: true,
spacingFactor: 1.0,
grid: false,
padding: 0,
anime: true,
circle: false,
userZoomingEnabled: true
}
)# wrk =
# wrk
# |> Workflow.react_until_satisfied("The sentient potato plots the demise of humanity")Workflow.raw_reactions(wrk)wrk.graph
|> Kino.Cytoscape.new(
layout_options: %{
name: "cose",
fit: false,
directed: true,
avoidOverlap: true,
spacingFactor: 1.0,
grid: true,
padding: 0,
anime: true,
circle: true,
userZoomingEnabled: true
}
)Instructor prompts LLMs to follow a JSON schema (modeled via ecto). It will retry a defined amount of times (3 by default) until the raw string returned from the LLM meets validation to become the defined contract.
Instructor's capabilities to extract structured outputs are immensely useful and support very common use cases with LLMs.
We can piece together similar capabilities in a Runic workflow but componentized in a few parts:
- Step(s) for building a prompt to request data that meets the schema definition
- Consider predefined prompts with templates and required inputs
- Step(s) for hitting the LLM with an API request (e.g wrap Req like above)
- Intermediate steps to extracting the response payload content
- Intermediate rules or looping for handling API request errors (e.g. token invalid, timeout, rate limit)
- Rules + state loop for checking if the payload returned meets criteria
- Returning the valid data
-
Goal: Describe domain / problem and use cases surrounding what the data represents
- List names of fields and describe what the fields are for
-
Define the JSON schema between
<schema></schema>tags -
Warn that we must only return JSON with valid fields based on the described types
-
Inject User / Content to extract data from
Our goal is to take documents which may contain useful knowledge about known entities (Named Entity Recognition) and collect connections between them (facts).
Triplet Fact Model:
(entity) -- relationship -- (other_entity)
sourceA known entitytargetAnother known entityrelationshipConnection or edge connecting the source and target- Relationship might have "properties"
defmodule Fact do
use Ecto.Schema
import Ecto.Changeset
@primary_key false
embedded_schema do
field(:source, :string)
field(:target, :string)
field(:relationship, :string)
end
def schema,
do: """
{
"type": "object",
"properties": {
"source": {"type": "string"},
"target": {"type": "string"},
"relationship": {"type": "string"}
}
}
"""
def new(params) do
%__MODULE__{}
|> cast(params, [:source, :target, :relationship])
|> validate_required([:source, :target, :relationship])
|> case do
%{valid?: false} = changeset ->
{:error, changeset}
%{valid?: true} = changeset ->
{:ok, apply_changes(changeset)}
end
end
endvalid_params = %{
"source" => "starwars",
"target" => "media_franchise",
"relationship" => "is_a",
}
invalid_params = %{
"source" => "starwars",
"relationship" => 42,
}Fact.new(invalid_params)Fact.new(valid_params)defmodule KnowledgeBase do
def research_assistant_prompt(query) do
[
%{
role: :system,
content: """
You are a research assistant with deep domain knowledge in every subject.
Your job is to create thorough reports detailing the core concepts, ideas, and models
of a subject. Fulfill the user's request and expound into ideas around the user query if it's important
to understanding the full picture.
These reports are being ingested into a knowledge base and your responses should show an understanding
of the reponsibility for factuality and nuance including potentially many perspectives and contexts.
Thus your usual process for making these reports is to first ask:
- "What are the core ideas, models, and concepts to understand this inquiry"
- Then break down each idea to understand it effectively then describe how to apply that knowledge for the goal of the user's inquiry.
Format your report in practical markdown and be extensive and thorough.
"""
},
%{role: :user, content: query}
]
end
def generate_edges_prompt(document) do
[
%{
role: :system,
content: """
You are a knowledge graph extraction assistant that returns a list of JSON.
You are doing your best to identify connections and relationships in the text that
you're sure are a notable person, place, idea, or thing worth modeling into a helpful knowledge graph.
All entities you find must be in a normalized lowercase snake_case format or else mayhem will ensue.
You always return a valid JSON array where each array item is an object with the fields source, target, and relationship.
You return nothing but valid JSON.
This is the JSON schema you must adhere to:
<schema>
{
"type": "array",
"items": #{Fact.schema()}
}
</schema>
"""
},
%{role: :user, content: document}
]
end
def ask_for_followup_questions_prompt(facts) when is_list(facts) do
[
%{
role: :system,
content: """
You are a research assistant tasked with asking salient followup questions to further explore the facts given.
You are given a list of facts in the form of a knowledge graph triplet containing two subjects and a relationship.
You must return the top 10 salient questions that can further explore any subject or relationship with the purpose
of expanding the knowledge in the graph. Never return any more than 10 questions.
You return nothing but a JSON array containing a list of followup questions.
The JSON schema you must adhere to:
<schema>
{
"type": "array",
"items": {
"type": "string",
}
}
</schema>
"""
},
%{
role: :user,
content: """
### Facts
#{Enum.map(facts, fn fact ->
"* #{fact.source} #{fact.relationship} #{fact.target} \\n"
end)}
"""
}
]
end
def extract_kg_edges(maybe_json) do
extract_json_array(maybe_json, Fact)
end
def extract_json_object(maybe_json_string, schema_module) when is_binary(maybe_json_string) do
case JSON.decode(maybe_json_string) do
{:ok, json} ->
extract_json_object(json, schema_module)
error ->
error
end
end
def extract_json_object(params, schema_module) do
case schema_module.new(params) do
{:ok, cmd} ->
cmd
{:error, msg} = result ->
Logger.error(msg)
result
end
end
def extract_array_of_strings(text) do
case Regex.scan(~r/\[.*\]/s, text) do
[[match]] ->
case JSON.decode(match) do
{:ok, array} ->
array
error ->
error
end
[] ->
{:error, :not_found}
_ ->
{:error, :unexpected_match_format}
end
end
def extract_json_array("[" <> _rest = maybe_json_string, schema_module)
when is_binary(maybe_json_string) do
case JSON.decode(maybe_json_string) do
{:ok, json} ->
extract_json_array(json, schema_module)
error ->
error
end
end
def extract_json_array(text, schema_module) when is_binary(text) do
case Regex.scan(~r/\[.*\]/s, text) do
[[match]] -> extract_json_array(match, schema_module)
[] -> {:error, :not_found}
_ -> {:error, :unexpected_match_format}
end
end
def extract_json_array(json_array, schema_module) when is_list(json_array) do
Enum.reduce(json_array, [], fn params, acc ->
case schema_module.new(params) do
{:ok, cmd} ->
[cmd | acc]
{:error, msg} ->
Logger.error(msg)
acc
end
end)
end
def extract_array(_, _), do: {:error, :invalid_input}
def extract_json_array(_, _), do: {:error, :invalid_json}
end- Generate a report on the given subject
- Generate an edge list of trie facts as JSON structured output
- Build
%Fact{}structs from decoded JSON
generate_research_report =
rule(
if: fn
{:query, user_query} when is_binary(user_query) ->
true
_ -> false
end,
do: fn {:query, user_query} ->
prompt = KnowledgeBase.research_assistant_prompt(user_query)
{:report,
LLMTools.generate_response(
model: model,
api_key: llm_api_key,
max_completion_tokens: 2048,
url: llm_api_url,
messages: prompt
)}
end,
name: :generate_research_report
)
extract_report =
rule(
fn {:report, {:ok, %{status: 200} = response}} ->
LLMTools.extract_llm_response(response)
end,
name: :extract_report
)
simple_kg =
Runic.workflow(
name: "kg_workflow",
rules: [
generate_research_report,
extract_report
]
)
generate_kg_facts =
step(
fn report ->
kg_prompt = KnowledgeBase.generate_edges_prompt(report)
LLMTools.generate_response(
model: model,
api_key: llm_api_key,
max_completion_tokens: 4096,
url: llm_api_url,
messages: kg_prompt
)
|> case do
{:ok, %{status: 200} = response} ->
response
|> LLMTools.extract_llm_response()
|> KnowledgeBase.extract_json_array(Fact)
{:ok, %{status: 400} = response} ->
dbg(response.body, label: "extract_facts generation failed")
end
end,
name: :generate_kg_facts
)
simple_kg =
simple_kg
|> Workflow.add(generate_kg_facts, to: {:extract_report, :reaction})simple_kg.graph
|> Kino.Cytoscape.new(
layout_options: %{
name: "breadthfirst",
fit: true,
directed: true,
avoidOverlap: true,
spacingFactor: 1.0,
grid: false,
padding: 0,
anime: true,
circle: false,
userZoomingEnabled: true
}
)ran_wrk =
simple_kg
|> Workflow.plan_eagerly({:query, "Elixir"})
|> Workflow.react_until_satisfied()ran_wrk = ran_wrk |> Workflow.plan_eagerly() |> Workflow.react_until_satisfied()edges =
ran_wrk
|> Workflow.raw_productions()
|> IO.inspect()
|> Enum.find(&is_list/1)
|> Enum.map(fn %Fact{} = fact ->
%{data: %{
id: "#{fact.relationship}-#{fact.source}#{fact.target}" |> :erlang.phash2(),
label: "#{fact.relationship}",
source: fact.source,
target: fact.target
}}
end)
|> dbg()edges
|> Kino.Cytoscape.new(
layout_options: %{
name: "cose",
fit: false,
directed: true,
avoidOverlap: true,
spacingFactor: 1.0,
grid: true,
padding: 0,
anime: true,
circle: true,
userZoomingEnabled: true
}
)- Once the initial research report is generated
- Generate followup questions to explore more in the graph
- Generate reports to answer each followup question
- Generate knowledge graph edges for every subject
- Aggregate all edges
followup_questions =
step(
fn facts ->
prompt =
KnowledgeBase.ask_for_followup_questions_prompt(facts)
LLMTools.generate_response(
model: model,
api_key: llm_api_key,
max_completion_tokens: 512,
url: llm_api_url,
messages: prompt
)
|> LLMTools.extract_llm_response()
|> KnowledgeBase.extract_array_of_strings()
end,
name: :ask_followup_questions
)
generate_followup_reports =
map(
fn question ->
prompt = KnowledgeBase.research_assistant_prompt(question)
{:follow_up_report,
LLMTools.generate_response(
model: model,
api_key: llm_api_key,
max_completion_tokens: 1024,
url: llm_api_url,
messages: prompt
)}
end,
name: :generate_followup_reports
)
handle_follow_up_reports =
rule(
fn {:follow_up_report, {:ok, response}} ->
kg_prompt =
response
|> LLMTools.extract_llm_response()
|> KnowledgeBase.generate_edges_prompt()
LLMTools.generate_response(
model: model,
api_key: llm_api_key,
max_completion_tokens: 2048,
url: llm_api_url,
messages: kg_prompt
)
|> case do
{:ok, %{status: 200} = response} ->
response
|> LLMTools.extract_llm_response()
|> KnowledgeBase.extract_json_array(Fact)
{:ok, %{status: 400} = response} ->
dbg(response.body, label: "extract_facts generation failed")
end
end,
name: :handle_follow_up_reports
)
extended_kg =
simple_kg
|> Workflow.add(followup_questions, to: :generate_kg_facts)
|> Workflow.add(generate_followup_reports, to: :ask_followup_questions)
|> Workflow.add(handle_follow_up_reports)extended_kg.graph
|> Kino.Cytoscape.new(:dag)# ran_wrk =
# extended_kg
# |> Workflow.plan_eagerly("elixir")
# |> Workflow.react_until_satisfied()
# |> Workflow.plan_eagerly()
# |> Workflow.react_until_satisfied()# ran_wrk
# |> Workflow.plan_eagerly()
# |> Workflow.next_runnables()# edge_list =
# ran_wrk
# |> Workflow.raw_productions()
# |> Enum.filter(fn
# [%Fact{} | _] ->
# true
# _else ->
# false
# end)
# |> Enum.flat_map(fn facts ->
# Enum.map(facts, fn fact ->
# %{
# data: %{
# id: "#{fact.relationship}-#{fact.source}#{fact.target}" |> :erlang.phash2(),
# label: "#{fact.relationship}",
# source: fact.source,
# target: fact.target
# }
# }
# end)
# end)
# |> dbg()defmodule WorkflowSupervisor do
use DynamicSupervisor
def start_link(_) do
DynamicSupervisor.start_link(__MODULE__, [], name: __MODULE__)
end
@impl true
def init(_) do
DynamicSupervisor.init(strategy: :one_for_one)
end
def find(id) do
id
|> WorkflowRunner.via()
|> GenServer.whereis()
end
end
defmodule WorkflowRunner do
use GenServer
alias Runic.Workflow
require Logger
# id -> pid
def via(workflow_id) when is_binary(workflow_id) do
{:via, Registry, {WorkflowRegistry, {__MODULE__, workflow_id}}}
end
def plan(workflow_id, input) do
GenServer.call(via(workflow_id), {:plan, input})
end
def run(workflow_id, input) do
GenServer.cast(via(workflow_id), {:run, input})
end
def get(workflow_id) do
GenServer.call(via(workflow_id), :get)
end
def state(workflow_id) do
GenServer.call(via(workflow_id), :state)
end
def halt(workflow_id) do
GenServer.call(via(workflow_id), :halt)
end
def child_spec(%{id: workflow_id} = session) do
%{
id: {__MODULE__, workflow_id},
start: {__MODULE__, :start_link, [session]},
restart: :transient
}
end
def start_link(%{id: workflow_id} = session) do
GenServer.start_link(
__MODULE__,
session,
name: via(workflow_id)
)
end
def start(session) do
DynamicSupervisor.start_child(
WorkflowSupervisor,
{__MODULE__, session}
)
end
def init(%{workflow: %Workflow{}} = session) do
session =
session
|> Map.put(:active_tasks, MapSet.new())
{:ok, session}
end
def handle_call(:get, _from, session) do
{:reply, session.workflow, session}
end
def handle_call(:state, _from, session) do
{:reply, session, session}
end
def handle_cast({:run, input}, session) do
workflow = Workflow.plan_eagerly(session.workflow, input)
session = %{session | workflow: workflow}
enqueue_tasks(session)
{:noreply, session}
end
def handle_info({ref, {_runnable_key, workflow}}, session) do
Logger.debug("### Task completed")
Process.demonitor(ref, [:flush])
wrk =
session.workflow
|> Workflow.merge(workflow)
|> Workflow.plan_eagerly()
session = %{
session
| workflow: wrk
# active_tasks: MapSet.delete(session.active_tasks, runnable_key)
}
if Workflow.is_runnable?(wrk) do
Logger.info("### Workflow is runnable")
enqueue_tasks(session)
else
Logger.info("### Workflow is resolved")
end
{:noreply, session}
end
def handle_info(msg, session) do
Logger.debug("## Workflow Runner unhandled_message #{inspect(msg)}")
{:noreply, session}
end
defp enqueue_tasks(session) do
session.workflow
|> Workflow.next_runnables()
|> Enum.reject(fn {step, fact} ->
MapSet.member?(session.active_tasks, {step.hash, fact.hash})
end)
|> Enum.reduce(session, fn {step, fact}, session ->
key = {step.hash, fact.hash}
Task.Supervisor.async(TaskRunner, fn ->
{key, Runic.Workflow.invoke(session.workflow, step, fact)}
end)
%{session | active_tasks: MapSet.put(session.active_tasks, key)}
end)
end
end
defmodule ManageWorkflows do
def start_runner(%Runic.Workflow{} = workflow) do
id = Ecto.UUID.generate()
session = %{id: id, workflow: workflow}
with {:ok, _} <- WorkflowRunner.start(session) do
{:ok, id}
end
end
def run_workflow(id, input) do
WorkflowRunner.run(id, input)
end
endKino.start_child!({Registry, name: WorkflowRegistry, keys: :unique})Kino.start_child!({WorkflowSupervisor, []})Kino.start_child!({Task.Supervisor, name: TaskRunner}){:ok, workflow_id} = ManageWorkflows.start_runner(extended_kg)ManageWorkflows.run_workflow(workflow_id, {:query, "elixir"})# WorkflowRunner.get(workflow_id)
# |> Map.get(:graph)
# |> Kino.Cytoscape.new()workflow = WorkflowRunner.get(workflow_id)
edge_list =
workflow
|> Workflow.raw_productions()
|> dbg()
|> Enum.filter(fn
[%Fact{} | _] ->
true
_else ->
false
end)
|> Enum.uniq()
|> Enum.flat_map(fn facts ->
Enum.map(facts, fn fact ->
%{
data: %{
id: "#{fact.relationship}-#{fact.source}#{fact.target}" |> :erlang.phash2(),
label: "#{fact.relationship}",
source: fact.source,
target: fact.target
}
}
end)
end)edge_list
|> Kino.Cytoscape.new()
